conditioner
■ Highly intelligent air conditioner system is with larger Cooling/Heating capacity.
Corrosion proof coated material case which is corrosion proof and suitably used in the Offshore environment.
■ Automatic self-test failure program, automatic switch setting.
■ Use of brand-name expansion valve as a throttling element, according to load flexibility in adjusting the refrigerant flowing.
■ Use of corrosion proof copper tube and fins, heat transfer efficiency is high。Stainless steel material case.
■ With brand microcomputer automatic control system, with automatic fault diagnosis function, running, saving time, saving electricity.
■ The high quality components are used to ensure the long-term efficient operation goes well. Environmentally with new R22,R417A, R407CA ,R410A Refrigerant: As standard, the marine type air conditioners come with refrigerant precharged. The new refrigerant is not only environmentally friendly, it also provides higher heating and cooling efficiency for low energy consumption.
conditioner
■ Highly intelligent air conditioner system is with larger Cooling/Heating capacity.
Corrosion proof coated material case which is corrosion proof and suitably used in the Offshore environment.
■ Automatic self-test failure program, automatic switch setting.
■ Use of brand-name expansion valve as a throttling element, according to load flexibility in adjusting the refrigerant flowing.
■ Use of corrosion proof copper tube and fins, heat transfer efficiency is high。Stainless steel material case.
■ With brand microcomputer automatic control system, with automatic fault diagnosis function, running, saving time, saving electricity.
■ The high quality components are used to ensure the long-term efficient operation goes well. Environmentally with new R22,R417A, R407CA ,R410A Refrigerant: As standard, the marine type air conditioners come with refrigerant precharged. The new refrigerant is not only environmentally friendly, it also provides higher heating and cooling efficiency for low energy consumption.
Spec. model | Cooling/ Heating Capacity (BTU/h) | Power Cooling/ Heating Consumption (W) | Voltage(V) Frequent(Hz) | Air flow M3/ h | Size(mm) Indoor Outdoor |
CYF-2.5 |
9000/9800 | 742/798 | 110/60 208-230/60 220-240/50/60 |
540 | 790*265*170 818*540*320 |
CYF-3.5 |
12000/13000 | 1068/1120 | 110/60 208-230/60 220-40/50/60 |
660 | 845*300*185 848*540*320 |
CYF-5.0 |
18000/20000 | 1800/1950 | 110/60 208-230/60 220-240/50/60 |
850 | 920*320*220 840*630*310 |
CYF-7.0 |
24000/24500 | 2360/2380 | 110/60 208-230/60 220-240/50/60 |
1100 | 1178*330*260 980*790*420 |
Spec. model | Cooling/ Heating Capacity (BTU/h) | Power Cooling/ Heating Consumption (W) | Voltage(V) Frequent(Hz) | Air flow M3/ h | Size(mm) Indoor Outdoor |
CYF-2.5 |
9000/9800 | 742/798 | 110/60 208-230/60 220-240/50/60 |
540 | 790*265*170 818*540*320 |
CYF-3.5 |
12000/13000 | 1068/1120 | 110/60 208-230/60 220-40/50/60 |
660 | 845*300*185 848*540*320 |
CYF-5.0 |
18000/20000 | 1800/1950 | 110/60 208-230/60 220-240/50/60 |
850 | 920*320*220 840*630*310 |
CYF-7.0 |
24000/24500 | 2360/2380 | 110/60 208-230/60 220-240/50/60 |
1100 | 1178*330*260 980*790*420 |
