1.1. The adoption of international famous brand compressor, industrial machine design, makes the system safety and reliability, heating/cooling with high efficiency, long life of operation
1.2.Suitably used in the hazardous area for the oil, gas, petrochemical, pharmaceutical and marine industry .
1.3.There are various of types such as high temperature type, low temperature type ,which can satisfy different requests.
1.4.Advanced technology on anti-corrosion and anti-dust.
1.5. Optional refrigerant types of R22,R134A,R417A,R407C
1.6.This type of explosion proof split air conditioner is up to the standards of the products quality surveillance of national explosion-proof electrification, and has obtained the explosion proof certificate . Such explosion proof split wall mount air conditioners can be used in Used in the hazard area:
Zone 1,Zone 2 ,Groups IIA,IIB,IIC (IEC hazard area classification),
Class 1/Division 1,Class 1/Division 2, Group B,C,D area.(NEC hazard area classification).
Category 2G,3G(ATEX hazard area classification)
1.7.Explosion-proof mark : Exdmb Ⅱ BT4, Exdmb Ⅱ CT4 .Explosion proof protection can be designed according to the ambient environment.
1.1. The adoption of international famous brand compressor, industrial machine design, makes the system safety and reliability, heating/cooling with high efficiency, long life of operation
1.2.Suitably used in the hazardous area for the oil, gas, petrochemical, pharmaceutical and marine industry .
1.3.There are various of types such as high temperature type, low temperature type ,which can satisfy different requests.
1.4.Advanced technology on anti-corrosion and anti-dust.
1.5. Optional refrigerant types of R22,R134A,R417A,R407C
1.6.This type of explosion proof split air conditioner is up to the standards of the products quality surveillance of national explosion-proof electrification, and has obtained the explosion proof certificate . Such explosion proof split wall mount air conditioners can be used in Used in the hazard area:
Zone 1,Zone 2 ,Groups IIA,IIB,IIC (IEC hazard area classification),
Class 1/Division 1,Class 1/Division 2, Group B,C,D area.(NEC hazard area classification).
Category 2G,3G(ATEX hazard area classification)
1.7.Explosion-proof mark : Exdmb Ⅱ BT4, Exdmb Ⅱ CT4 .Explosion proof protection can be designed according to the ambient environment.
Model Spec. | BCKT-2.5 | BCKT-3.5 | BCKT-5.0 | BCKT-7.0 |
Cooling(BTU/h) | 9000 | 12000 | 18000 | 24000 |
Power consumption(W) | 860 | 1130 | 1520 | 2150 |
Air flow M3/ h | 520 | 650 | 800 | 920 |
Size (mm) W*H*D | 560*380*620 | 660*430*700 | 660*430*770 | 900*700*1100 |
Voltage /Frequent | 110V/220V | |||
50/60Hz | ||||
Ex Mark: | Exdmb Ⅱ BT4, Exdmb Ⅱ CT4 |
Model Spec. | BCKT-2.5 | BCKT-3.5 | BCKT-5.0 | BCKT-7.0 |
Cooling(BTU/h) | 9000 | 12000 | 18000 | 24000 |
Power consumption(W) | 860 | 1130 | 1520 | 2150 |
Air flow M3/ h | 520 | 650 | 800 | 920 |
Size (mm) W*H*D | 560*380*620 | 660*430*700 | 660*430*770 | 900*700*1100 |
Voltage /Frequent | 110V/220V | |||
50/60Hz | ||||
Ex Mark: | Exdmb Ⅱ BT4, Exdmb Ⅱ CT4 |
